Part Number : AVXWALL-PLUS, 1x Videowall Processor, 2x Rack-mounting Kit, 1x UL AC Power Cord, 1x Installation Software CD, 1x User's Manual
4K Modular Video Wall Processor, FPGA Fully Customizable with KVM control
Avenview AVXWALL+ Video Wall Processor is a modern and multi-function processor based on FPGA and PCI-E architecture. Hardware-based architecture and modular design makes it not only stable and reliable but also being able to be personalized and customized with different types of card inputs and outputs. This new generation Video Wall Processor supports signal preview, video-wall mirroring (Confidence Monitoring), audio-video synchronized switching, scrolling text and Real-time PC control using KVM function.
The AVXWALL+ is an all-in-one video wall processor designed for smart control centers. It can be widely used for security, traffic control, power stations, television and broadcasting, finiancial institutions, exhibitions, educational institutes, etc.
- Modular input and output chassis design. - Supports 4K ultra high resolution image and high-quality P2P (Pixel to Pixel) screen resolution, - High-performance system supports LCD, DLP and LED video wall of any size and layout, - Users can insert input card, output card, and control card into any card slot -Any to Any, - Users can control PC sources directly with mouse and keyboard, - HD dynamic scrolling text function allowing users to define a group of scrolling text with different styles to publish messages and slogans, - Supports analog/embed audio input and output allowing users to manage audio and video signals synchronically, - On Screen Control, allows users to control the whole video wall using keyboard and mouse, users can open, resize, move and relocate input signals window without the need of any control software, - Supports output image synchronization without row by row delay, - Can manage up to 4 video wall groups with different resolution at the same time, - Supports RS232/485 serial port, infrared interface, relay control interface for third party device control, - Supports multi-user function allowing different users to login into the system and operate the processor at same time, - Allows storage of up to 128 presets, - Provides 60fps real-time mirroring high resolution video signal of the whole video wall (Confidence Monitoring) over HDMi or IP Stream, - Supports CVBS, YPbPr, VGA, DVI, HDMI, SDI, DisplayPort, UTP and optical fiber, - Full screen modes, zoom, image crop and adjustable size & position through software, - Background Image storage, - EDID Management.
