Part Number : CCS-DID, Chairman Unit Short Microphone (39cm) and 2,5m Cable
Compact discussion management
The Bosch Delegate Unit is intended for use with the Bosch CCS 900 Conference System. Delegate Unit features a built-in speaker and an adjustable gooseneck microphone. It's Possible-To-Speak LED illuminates to indicate when it is possible to activate the microphone. The CCS-D Delegate Unit's loudspeaker mutes automatically while in use, features a red LED ring to indicate power and a headphone output with dedicated level control.
Possible‑To‑Speak A so called ‘Possible‑To‑Speak’ indicator is build‑in showing if it is possible to switch on the microphone. This functionality is shown by a white LED combined with the ‘microphone on’ indicator.
Microphone with flexible stem and light ring The microphone is mounted on a flexible stem, which is easily adjustable to suit personal preferences. It also allows two people to use the same delegate unit as they can pull the microphone towards them when required to speak. Incorporated into the head of the microphone is a light ring which illuminates red to indicate when the microphone is on.
Built‑in loudspeaker Loudspeaker volume is set centrally at the Control Unit for all delegate units. To prevent acoustic feedback, the built‑in loudspeaker is automatically muted when the microphone is on.
Two headphone sockets Two 3.5 mm (0.14 in) stereo headphone sockets (wired for mono) allow two pairs of headphones to be connected so two delegates can simultaneously use the unit. It is also possible to connect a tape recorder to one headphone socket, and use the other headphone socket to listen to the proceedings.
Built‑in volume control for headphones The headphone volume level can be adjusted by means of a thumbwheel on the unit for maximum comfort.
Compact, attractive design Featuring modern, unobtrusive styling and finished in charcoal gray these units make a valuable addition to any venue
Standard or Extended Length Microphone Stems The delegate units are available with standard 2,5m Cables and 39cm microphone stem lengths.
Controls and Indicators
• Microphone on/off button • Rotary volume control for adjusting headphone volume • Loudspeaker, automatically muted when microphone is on and/or headphones are connected • Possible‑To‑Speak indicator (white LED) • Microphone ‘on’ indicator (red LED) • Light ring indicator on microphone stem, lights up red when microphone is on Interconnections • 1 x 2 m (78.7 in) cable terminated with a 7‑pole male connector for loop-through connection to other delegate or chairman units, or to a Control Unit • 1 x 7‑pole circular female connector for loop-through connection to other delegate or chairman units • 2 x 3.5 mm (0.14 in) stereo headphone sockets
