Part Number : CCS-CMID, Chairman Unit Short Microphone (39cm) and 2,5m Cable
Compact discussion management
The Bosch CCS Chairman Unit is intended for use with the Bosch CCS 900 Conference System. Much like the Delegate Unit, The Chairman Unit features a built-in speaker and an adjustable gooseneck microphone. The Chairman Unit provides added muting control over delegates. Permanently or temporarily mute delegate microphones in order to establish control over dialog. The CCS Chairman Unit's loudspeaker mutes automatically while in use, features a red LED ring to indicate power and a headphone output with dedicated level control.
Priority button for chairman microphone In addition to the ‘microphone on’ button the chairman units feature a ‘chairman priority’ button. When pressed the priority button causes all currently active delegate microphones to be temporarily or permanently muted.
Temporary or permanent muting of delegate microphones The ‘chairman priority’ button can be set to mute delegate microphones on a temporary or permanent basis. On the temporary setting, delegate microphones are muted only as-long as the chairman has the priority button pressed down. On the permanent setting delegates must reactivate their microphone after a ‘chairman priority’ announcement by pressing the ‘microphone on’ button on their delegate unit. Activation of the permanent mute option is carried out by setting an internal switch, which can be accessed by removing a small plastic plate on the base of the chairman unit.
Optional chime tone facility for preceding chairman announcements An optional chime tone can be selected to precede chairman priority calls. Activate the chime tone option by setting an internal switch; this can be accessed by removing a small plastic plate on the base of the chairman unit.
Standard or extended length microphone stems The chairman units are available with standard 2,5m Cables and 39cm microphone stem lengths.
Controls and Indicators • Microphone on/off button • Chairman priority button • Rotary volume control for adjusting headphone volume • Loudspeaker, automatically muted when microphone is on and/or headphones are connected • Internal switch for selection of chairman announcement chime tone • Internal switch for temporary or permanent muting of delegate microphones when chairman priority button is pressed • Microphone has ‘on’ indicator (red LED) • Light ring indicator on microphone stem, lights up red when microphone is on • No Possible‑To‑Speak functionality and indicator is required because a Chairman Unit can always switch‑on the microphone, no matter the number of delegates speaking
Interconnections • 1 x 2 m (78.7 in) cable terminated with a molded 7-pole circular male connector, for loop-through interconnection to delegate unit or Control Unit • 1 x 7-pole circular female connector for loop-through interconnection to delegate units • 2 x 3.5 mm (0.14 in) stereo headphone sockets
